The WOLLER BS-550 LICHT twin-shaft circular log saw machine is designed for longitudinal sawing of logs with a diameter of 120 to 550 mm into a carriage and unedged boards. The machine is used as a first row machine, high power production. The machine, like all BS series machines, is designed for sawing logs in one pass, into unedged sawn timber with good surface quality. At the request of the customer, the machine can be equipped with our near-station equipment. Technical characteristics: - log diameter: 0.12-0.55 m - log length: 2.5-6.5 m - saw diameter: 550-750 mm * - saw shaft diameter: 90 mm - number of saws (max): 8 pcs - saw shaft motors power: 2 x 55 kW ** feed logs: 3 kW - feed speed: 1-30 m / min - machine dimensions (L x W x H): 8.5 x 2.5 x 2.15 m - machine weight (approx): 4300 kg

Designed for precise cutting of workpieces along the length, release of material with perfectly flat end surfaces, as well as removal of defective areas of wood. Maximum board width: 300 mm Maximum board length: 6500 mm Cutting height: up to 100 mm Saw blade diameter: 350 mm Motor power: - sawing: 2.2 kW x 6 pcs-feed: 3 kW Feed rate: to be specified when ordering Overall dimensions of cross-cutting, m: 7 x 1.6 x 1.3 Weight: 1350 kg

Designed to produce cylindrical (round) parts, cuttings from square blanks of various types of wood, as well as synthetic materials. It is used for the production of: Furniture Products for household use Shafts for shovels, rakes, etc. Stakes, dowels for Sports equipment Diameter of the resulting product, mm: 10 - 60 Material feed rate, m / min: 6; nine; 12 The smallest workpiece length, mm: 350 Number of cutter head knives, pcs: 2 Shaft rotation frequency, rpm: 4000 Number of electric motors, pcs: 2 Material feed motor power, kW: 0.75 Cutter head motor power, kW: 3 Dimensions , mm (length * width * height) 850х500х995 Weight: 270kg.

Designed for precise cutting of workpieces along the length, release of material with perfectly flat end surfaces, as well as removal of defective areas of wood. Workpiece length: 500-1300 mm Workpiece width: up to 260 mm Workpiece thickness: 15-60 mm Saw blade size: 350х30 Number of circular saws: 2 pieces Saw drive power: 2.2 kW x 2 Feed power: 1.1 kW Feed speed : 5 m / min Machine dimensions (L x W x H), mm: 2000х1500х1100 Machine weight, kg: 300 ± 5

Designed for longitudinal sawing of logs in order to obtain carriages and unedged boards. Raw materials are fed into the saw unit using a caterpillar transport system. The log is fixed using automatic pneumatic clamps. WOLLER BS-550 LINIE ensures reliable operation even with 24/7 loading. Its design meets all modern safety requirements. Ease of setting the distance between the saws, ensures that the lumber of the desired size is quickly obtained. The machine has a colossal productivity of 300 - 400 m³ of round timber per shift. At the request of the customer, the machine can be completed with our near-station equipment. The maximum diameter of the log, mm: 120-550 Average max. diameter of a log taking into account curvature, mm: 300-500 Minimum length of a log, mm: 2500 Number of installed saws: 6 Diameter of saws, mm: 550/650/750 (Optional) Diameters of saw shafts, mm: 90 Number of revolutions of saw shafts, rpm : 3800 Power of saw shaft motors, kW: 55, 75, 90, 110 (on request) Feed speed, m / min: 1-30 Power of feed motors, kW: 17 Machine dimensions LxWxH, mm: 14700x2400x4050Weight, kg: 16700

The WOLLER BS-550 twin-shaft circular log saw machine is designed for longitudinal sawing of logs with a diameter of 120 to 550 mm into two-edged cant and non-edged board. The machine is used as a first row machine, high power production. The machine is designed for sawing logs in one pass, on unedged sawn timber with good surface quality. At the request of the customer, the machine can be completed with our near-station equipment. The maximum diameter of the log, mm: 120-550 Average max. diameter of a log taking into account curvature, mm: 300-500 Minimum length of a log, mm: 2500 Number of installed saws: 6 (8) (Option) Diameter of saws, mm: 550/650/750 (Optional) Diameters of saw shafts, mm: 90 Number speed of saw shafts, rpm: 3800 Power of saw shaft motors, kW: 55, 75, 90, 110 (on request) Feed speed, m / min: 1-30 Power of feed motors, kW: 13.4 Machine dimensions LxWxH, mm: 12300x2650x2250 Weight , kg: 12000

Designed for longitudinal cutting of a carriage (two-, three- and four-edged beams) obtained on a WOLLER 550 log saw into edged lumber. The machine is equipped with a sturdy frame made of thick-walled profiled metal. The workpieces are fed by chain conveyors and driven rollers. The control panel can be located both on one and on the other side. Maximum cutting height, mm: 180 Diameter of circular saws / shaft diameter, mm: 350/70 Max. number of installed saws on each shaft, pcs: 10 Feed rate, m / min: 0-35 Power of motors: - lower spindle drive, kW: 30/45 - upper spindle drive, kW: 45 - feed drive, kW: 3.7Max. width of the saw set, mm: 620Max. width of the workpiece being sawn, mm: 700 Overall dimensions, mm: 3020х2170х1810 Machine weight, kg: 4200

Designed for longitudinal sawing with circular saws of two-three-four-edged cants into boards and cutting boards into workpieces of a given thickness with a mechanized feed. The machine is unpretentious in work, it is installed on a flat concrete platform. Simple and reliable design allows to operate the machine in two-shift mode without loss of product quality. The machine is specially designed for operation in unheated rooms and at low temperatures, since it does not have pneumatics and hydraulics. It is used to obtain high-quality sawn timber in enterprises and workshops of sawmills and for the production of joinery and construction products. Widely used in lines for processing small size, as well as for the production of pallet workpieces. Maximum cutting height, mm: 120 Maximum distance between extreme saws, mm: 990 Width of the receiving window, mm: 1100 Minimum length of the workpiece, mm: 1000 Feed speed is changed by pulleys, m / min30, 40, 50 (customer option) Feed speed (automatic) OPTION, m / min: up to 85 Saw diameter, mm: 400 Saw seat diameter, mm: 75 Saw shaft drive motor power, kW: 30 (45, 55) Feed motor power, kW : from 2Saw shaft rotation frequency, rpm: 4000 Machine dimensions (L x W x H), mm: 2050х1730х1350 Machine weight, kg: 1650
