Product Highlights
• Zenmuse Z15-A7 Gimbal for Sony a7S / a7R• Gimbal Provides 360° Camera Rotation• Collapsible Frame and Folding Props• Up to 18 Pound Total Take-Off Weight• Low Gimbal Mounting with Dampening• Retractable Landing Gear• DJI A2 Flight Control System• Supports Futaba FASST / DJI DESST Radios• Up 18 Minutes Flying at 12,000mAh• Compatible with iPad Ground Station
DJI Spreading Wings S900 Hexacopter
Frame
Diagonal Wheelbase
35.4" / 900 mm
Frame Arm Length
14.1 / 358 mm
Frame Arm Weight
Including Motor, ESC, and Propellers: 11.1 oz / 316 g
Center Frame Diameter
10.7" / 272 mm
Center Frame Weight
With Landing Gear Mounting Base and Servos: 2.6 lb / 1.2 kg
Landing Gear Dimensions
18.1 x 17.7 x 14.2 / 460 x 450 x 360 mm
Motor
Stator Size
1.6 x 0.6" / 41 x 14 mm
Motor Velocity Constant
KV: 400 rpm/V
Maximum Power Consumption
500 W
Weight
With Cooling Fan: 5.6 oz / 158 g
Electronic Speed Control (ESC)
Working Current
40 A
Working Voltage
6S LiPo
Signal Frequency
30 to 450 Hz
Drive PWM Frequency
8 kHz
Weight
With Cooling Fan: 1.2 oz / 35 g
Propeller
Type
Folding
Material
Plastic
Size
15 x 5.2" / 381 x 132 mm
Weight
0.5 oz / 13 g
Flight Parameters
Supported Flight Control Systems
DJI A2 and WooKong-M
Take-Off Weight
10.4 to 18.1 lb / 4.7 to 8.2 Kg
Total Weight
7.3 lb / 3.3 Kg
Battery Requirements
LiPo: 6S, 10000 to 15000 mAh, 15C (minimum)
Maximum Power Consumption
3000 W
Hover Power Consumption
1000 W at 15 lb / 6.8 Kg takeoff weight
Hover Time
18 minutes at 12000 mAh and 15 lb / 6.8 Kg takeoff weight
Operating Temperature
14 to 104°F/ -10 to 40°C
Packaging Info
Box Dimensions (LxWxH)
19.8 x 15.7 x 12.7"
DJI A2 Flight Control System for Multi-Rotor Aircraft
Supported ESC Output
400 Hz refresh frequency
Supported Transmitters
With Built-in Receiver: Futaba FASST series and DJI DESST series
Supported External Receivers
Futaba S-Bus, S-Bus2, DSM2
Other DJI Products Supported
Z15, H3-2D, iOSD, 2.4G Bluetooth Data Link, and S800 EVO
Hovering Accuracy (GPS Mode)
Vertical: ±1.6' / 0.5 mHorizontal: ±4.9' / 1.5 m
Maximum Wind Resistance
< 26.2 fps (8 m/s) / 17.9 mph (28.8 km/h)
Maximum Yaw Angular Velocity
150 deg/s
Maximum Tilt Angle
35°
Ascent/Descent
±19.7 fps / 6 m/s
Power Requirements
Maximum: 5 WTypical: 0.3 A at 12.5 V
System Requirements
Assistant Software: Windows 8, 7, or XP SP3 -- 32 or 64-bit
Operating Temperature
23 to 140°F / -5 to 60°C
Dimensions
Flight Controller: 2.1 x 1.5 x 0.6" / 54 x 39 x 14.9 mmIMU: 1.6 x 1.2 x 1" / 41.3 x 30.5 x 26.3 mmGPS-Compass Pro: 2.4" (diameter) x 0.6" / 62 mm (diameter) x 14.3 mmLED-BTU-I: 1.2 x 1.2 x 0.3" / 30 x 30 x 7.9 mmPMU: 39.5mm x 27.6mm x 9.8mm
Weight
Overall: 7.9 oz / 224 g
Packaging Info
Box Dimensions (LxWxH)
6.9 x 4.7 x 2.7"
DJI Zenmuse Z15-A7 3-Axis Gimbal for Sony a7S / a7R
Peripheral
Supported Camera
Sony a7S / a7R
Supported Lens
Sony FE 35mm f/2.8 ZA
Control Requirements
At least 4 spare receiver channelsS-Bus/PPM receiver supported
Software Requirements
For Assistant Software: Windows 8, 7, XP SP3 -- 32 or 64-bit
Electrical Characteristics
Working Current
Static Current: 200 mA at 25 VDynamic Current: 400 mA at 25 VLocked-Rotor Current: 4 A at 25 V
GCU BEC Output
10 A at 12 V
Transmit Power
GCU Wireless Video Transmission: 1 A at 12 V
Performance
Load Weight (Reference Value)
1.4 lb / (622 g) with Sony a7S, FE 35mm f/2.8 ZA lens, battery, lens hood, and SD Card 1.3 lb (580 g) with Sony a7SR, FE 35 mm f2.8 ZA lens, battery, lens hood, and SD Card
Controlled Angle Accuracy
±0.01°
Maximum Controlled Rotation Speed
Pan Axis: ±130°/s Tilt Axis: ±130°/sRoll Axis ±30°/s
Controlled Rotation Range
Pan Axis Control: ±360° continuous rotationTilt Axis Control: +50°:/-140° Roll Axis Control: ±40°
General
Power Requirements
GCU: 4S to 12 S LiPo (6S if using S800, S1000+)
Operating Temperature
14 to 122°F (-10 to 50°C)
Dimensions
Gimbal: 8.7 x 8.7 x 7.5" (220 x 220 x 190 mm)Camera Frame Dimensions: 5.6 x 3" (142 x 76 mm)GCU: 2.5 x 1.4 x 0.8" (64.2 x 34.1 x 19.5 mm)
Weight
Gimbal: 2.9 lb (1.3 kg)GCU: 2.2 oz (63 g)
Packaging Info
Box Dimensions (LxWxH)
10.0 x 9.449 x 9.37"
